CNC Turning Insert (M) (K) (S) - CNMG12/16

Material: Cemented Carbide
Sales Models: Factory-direct sales
  • CNMG12/16

  • NEK

  • 1

  • 1

  • Cubic Boron Nitride

  • Car

  • 1 Box- 10 PCS

  • CNC Tool

Availability:
Quantity:


CNC Turning Insert Overview

Engineered for rigorous numerical control cutting operations, the CNMG12/16 CNC turning inserts deliver precise material removal and consistent surface finishes across demanding machining environments. These turning blades are precision-manufactured to support heavy-duty operations, ensuring prolonged durability and reliable execution. Formulated from premium industrial-grade substrates, these inserts execute exact cuts while leaving a refined, smooth texture on the machined surface. Whether the project involves hardened metal alloys, industrial plastics, or composite structures, these lathe tool blades provide the structural integrity required to achieve superior dimensional accuracy. Upgrading your machining setup with these inserts translates to fewer tool changes, reduced downtime, and a more efficient workflow on the factory floor.

1. Material Composition & Advanced Coating Technology

The structural foundation of these vehicle blades relies on a carefully calibrated matrix of carbonized alloys, including dense tungsten titanium alloy, resilient high-speed steel, and specialized ceramic compounds. Each substrate is tailored to specific thermal and mechanical demands. Carbide and high-speed steel variants offer exceptional hardness and resistance to abrasive wear, making them ideal for rapid, heavy metal removal where intense friction is generated. Conversely, ceramic blades excel in extreme heat scenarios, maintaining their structural integrity when processing exceptionally hard materials.

To further enhance these base materials, the inserts undergo advanced CVD (Chemical Vapor Deposition) and PVD (Physical Vapor Deposition) coating processes. This surface treatment leaves a distinct, dark-tinted metallic sheen and creates a formidable thermal barrier. The coating significantly elevates oxidation resistance and high-temperature tolerance, dramatically extending the tool's lifespan during continuous, high-intensity cutting cycles. Achieving an accurate surface finish often requires transitioning through rough machining, half-finishing, and final finishing stages, and these coated materials ensure consistent performance across every phase.


2. Key Features & Insert Design

High Positioning Accuracy

Maintaining exact tolerances is critical. After replacing the blade, the microscopic shift of the knife tip position remains strictly within the allowable range of the workpiece machining accuracy. This ensures that operators do not need to constantly recalibrate the machine after every index.

Clamp Stability & Adaptability

The standardized CNMG12/16 specification design ensures perfect compatibility with internationally recognized external turning tool holders and internal boring bars. When secured, the contact surface between the blade, the knife pad, and the knife stem coordinates closely to absorb the intense impact and vibration generated during processing. The fit produces a satisfying, secure lock, ensuring the clamping force is distributed evenly without causing excessive stress that could damage the blade.

Optimized Chip Breaker Geometry

The front end of the blade is engineered with specialized chip breaker grooves tailored for finishing, semi-finishing, and roughing. This geometry ensures there are no obstacles, promoting a smooth chip discharge. As the metal is sheared, the chip breaker forces the material to curl and snap with a crisp acoustic signature, keeping the cutting zone clear and making it easy to monitor the processing process.

Convenience of Operation

The conversion and replacement process of the blade is designed to be highly convenient and rapid. Operators can index the insert swiftly, minimizing machine idle time and substantially improving overall work efficiency on the production line.


3. Operational Advantages & Performance

  • Excellent Accuracy: The vehicle blade facilitates rapid, efficient, and highly precise metal processing. From aggressive material removal to delicate fine processing and trimming, the sharp, tactile edge ensures the final output meets strict dimensional tolerances.

  • Excellent Wear Resistance: Thanks to the inherent hardness and abrasion resistance of the vehicle blade materials, these inserts withstand prolonged, intense processing operations. This durability translates to fewer replacements and a significantly extended service life.

  • Diversity & Versatility: The product line encompasses a wide variety of vehicle blades, including ordinary internal knives, external knives, cutting knives, and thread knives. This extensive selection meets a broad spectrum of different processing needs.

To assist operators in maximizing these advantages, we provide detailed cutting parameter recommendations. By adhering to suggested linear speeds, feed rates, and cutting depths, users can rapidly match the optimal cutting efficiency when working with challenging materials like steel, stainless steel, and titanium alloys.


4. Application Fields & Machining Capabilities

The vehicle blade is primarily utilized in the turning operation of metal processing, where the machine rotates the workpiece against the stationary cutting edge to ensure accurate shaping and dressing. These inserts are highly suitable for the processing of carbon steel, cast iron, copper, aluminum, stainless steel, and other non-ferrous metal materials.

Depending on the specific industrial requirement, these blades can be deployed across different levels of processing methods. They excel in coarse grinding (roughing) to remove large volumes of material quickly, semi-fine grinding to establish near-net shapes, and fine grinding (finishing) to achieve a mirror-like surface finish. This adaptability ensures they meet the strict processing requirements of various complex shapes, exact sizes, and specific surface roughness criteria demanded by modern manufacturing sectors.

CNMG12/16 CNC Turning Insert front view showing chip breaker geometry
CVD coated turning insert highlighting metallic sheen and surface treatment
Detailed edge profile of the CNC lathe tool blade
Multiple CNMG12 turning inserts arranged to show batch consistency






Industrial packaging for turning inserts ensuring safe delivery



CNC machining application demonstrating smooth chip discharge

Precision metal processing capabilities of the vehicle blade

Supplier Strength & Frequently Asked Questions

Our manufacturing facility operates under a rigorous quality management system, utilizing high-precision optical inspection equipment to guarantee the microscopic edge consistency and batch stability of every insert produced. Furthermore, all products are secured in industrial-grade packaging—specifically, shockproof and moisture-proof standard plastic boxes containing ten pieces each. This robust packaging prevents any edge collisions during transit, ensuring safe delivery for large-scale procurement. Backed by over 20 years of industry experience and an independent R&D team, we also support rapid prototyping and large-scale OEM/ODM production for special materials and non-standard custom shapes. Below are common inquiries regarding our production capabilities and terms:

How many years has your company had production experience?
Our company was established in 2000 and was reorganized in 2007 as NeK CNC tools Co.,Ltd. After so many years, our company has a team of terminal customers and a team of dealer customers. At present, we are one of the largest distributors of YG in China. We also have our own invested factory and our own OEM brand(NeK and SHITAEGER for insert)We are famous in Ningbo City, Zhejiang Province, China.

Do you have alloys for stainless steel, for titanium?
Our brand inserts' advantage is good at process steel and stainless steel. Recently, we have also introduced inserts for process titanium alloy materials.

That is the Minimum order quantity?
300~500 pcs. Foreign customers need to bear the freight by themselves.

That is the Production time?
We have a large stock of all the common styles on the market. A small number of special types' inserts need to be re-counted after communication.

What is the volume of plate production per month and per year?
50 million pcs/year

Do you have a representative office in Russia?
Not yet.

Can you make production of special items?
Yes.

do you have warehouse?
In China.

lead time for new items?
At present,High speed land transport for 15-20 days
                                                                          Air transport for 7-8 days

Turning insert production facility and optical inspection equipment
Advanced coating technology machinery for vehicle blades
Quality control testing phase for CNC lathe tool blades
Inventory and warehouse storage of standard plastic boxes
OEM and ODM brand packaging capabilities for NeK and SHITAEGER
Global distribution and shipping preparation for high-speed transport
