Drilling Insert-SP/WC

Drilling Insert-SP/WC Micro-Grain WC-Co Carbide for CNC Drilling and Milling Drilling Insert-SP/WC HRA 90-93 Cemented Carbide CNC Milling Tool SP/WC Drilling Insert for Precision Small-Diameter and Heavy-Duty Drilling Drilling Insert-SP/WC Rhombic and Square Carbide Inserts for CNC Metalworking Premium Drilling Insert-SP/WC WC-Co Carbide for CNC Drilling and Milling
  • Drilling Insert-SP/WC

  • NEK

  • 1

  • 1

  • 40cr 20crmnti

  • Car

  • 1 Box- 1 P

  • CNC Tool

Availability:
Quantity:

Drilling Insert SP/WC Overview & Material Excellence

The materials of drilling blades mainly include high-speed steel, cemented carbide, ceramics and cermet and other new tool materials. When handling demanding metalworking tasks, the composition of the insert dictates the success of the operation. Our SP and WC series drilling inserts are meticulously crafted from micro-grain WC-Co cemented carbide, achieving an impressive hardness rating of HRA 90-93. This exceptional substrate provides a dense, weighty feel and a distinct metallic sheen, reflecting its superior structural integrity. The characteristics of the drilling blade is that its design is usually for the special needs of drilling processing, such as the two main cutting edges of the drill are cut at the same time of rotation, the cross edge is located near the center axis of rotation, resulting in a large axial resistance. Blades of different materials will vary in these characteristics, such as carbide blades with higher hardness and wear resistance, while ceramic blades have better chemical stability and red hardness. To comprehensively cover varying hole diameters and depths, we provide distinct series differentiation: the WC series features a rhombic geometry ideal for small-diameter precision tasks, whereas the SP series utilizes a square profile engineered for medium to large-diameter heavy-duty material removal.

Micro-grain WC-Co cemented carbide drilling insert structure

Key Advantages & Engineering Innovations

The advantages of drilling blades are mainly reflected in the following aspects:

Drilling blades have become an indispensable tool in various industries due to their numerous benefits, which are elaborated upon in the points below:

1. High Efficiency & Optimized Chip Control

1. High efficiency: The drilling blade can significantly improve the processing efficiency of drilling, especially when processing materials with higher hardness. This is because the design and technology behind these blades are optimized for rapid material removal, allowing for faster penetration through tough substances. We enhance this efficiency through specialized coating and chip breaker technology. The optimized chip breaker geometry ensures that metal shavings curl and snap with a crisp, consistent sound, preventing long, stringy chips from tangling around the tool. Coupled with a custom wear-resistant coating that feels exceptionally smooth to the touch, this design effectively prevents built-up edge and ensures unobstructed chip evacuation even under heavy feed rates. Furthermore, the standardized indexable design supports rapid, precise insert replacement. Operators will notice a firm, reassuring click when indexing the insert, which drastically reduces machine downtime and elevates batch production output.

Optimized chip breaker technology for SP/WC drilling inserts

2. High Precision & Unyielding Stability

2. High precision: The design of modern drilling blades makes the dimensional accuracy and surface roughness of drilling holes well controlled. This precision is crucial in applications where the slightest deviation can lead to malfunction or structural weakness, ensuring that each hole meets the strictest quality standards. To guarantee this level of exactness, our inserts offer perfect tool holder compatibility. They integrate flawlessly with standard U-drill bodies and side-lock (SLN) holder systems such as BT30, BT40, and BT50. This exceptional compatibility translates to absolute clamping rigidity, eliminating micro-vibrations during high-RPM operations and maintaining strict diametrical tolerances from the top to the bottom of the hole.

BT30 BT40 BT50 tool holder compatibility for drilling inserts

3. Long Life & Interrupted Cut Resilience

3. Long life: The use of high-quality materials and advanced manufacturing processes of drilling blades has led to a significant extension of their service life. This durability reduces the frequency and cost of blade replacement, making them a cost-effective solution for long-term projects and high-volume production environments. By combining the extreme hardness of the carbide substrate with outstanding toughness, these inserts withstand the punishing impacts of interrupted cuts without fracturing, delivering a dependable and extended operational lifespan.

Application Scenarios & Material-Specific Solutions

In application scenarios, drill bits are widely used in drilling operations for various materials, including metals, non-metals, and composite materials. Especially in the fields of automotive manufacturing, aerospace, and mechanical manufacturing, the use of drill bits is more common. For instance, in the automotive manufacturing field, drill bits are used for machining holes in engine blocks and transmission housings; while in the aerospace field, drill bits are used for machining holes in high-precision components such as aircraft engine blades and fuselage structures. To maximize performance across these diverse sectors, we provide material-specific machining solutions. Whether you are dealing with the abrasive nature of cast iron, the gummy consistency of aluminum alloys, or the thermal challenges of titanium and stainless steel, we offer precisely matched insert grades and specialized cutting parameter guidelines to ensure optimal penetration rates and superior surface finishes.

Drilling Insert-Sp/Wc application in automotive and aerospace




Drilling Insert-Sp/Wc machining solutions for various metals



Supplier Capabilities & Frequently Asked Questions

How many years has your company had production experience?

Our company was established in 2000 and was reorganized in 2007 as NeK CNC tools Co.,Ltd. After so many years, our company has a team of terminal customers and a team of dealer customers. At present, we are one of the largest distributors of YG in China. We also have our own invested factory and our own OEM brand(NeK and SHITAEGER for insert) We are famous in Ningbo City, Zhejiang Province, China.

NeK CNC tools Co.,Ltd production facility in Ningbo

Do you have alloys for stainless steel, for titanium?

Our brand inserts' advantage is good at process steel and stainless steel. Recently, we have also introduced inserts for process titanium alloy materials, ensuring strong performance even when facing extreme temperatures and tough chip formations.

That is the Minimum order quantity?

300~500 pcs. Foreign customers need to bear the freight by themselves.

Large stock of standard drilling inserts ready for shipment

That is the Production time?

We have a large stock of all the common styles on the market. A small number of special types' inserts need to be re-counted after communication.

What is the volume of plate production per month and per year?

50 million pcs/year

Annual production capacity of 50 million pieces

Do you have a representative office in Russia?

Not yet.

Can you make production of special items?

Yes. We offer robust customization capabilities and technical support. Beyond standard dimensions, we provide non-standard size customization services. Whether you are dealing with deep-hole or shallow-hole machining scenarios, our engineering team supplies professional tool selection advice, tailored coating matching, and trial cutting technical support.

Customization and technical support for special drilling items

do you have warehouse?

In China.

lead time for new items?

At present,High speed land transport for 15-20 days
Air transport for 7-8 days

Secure packaging and warehouse storage in China
Global logistics and fast transport for drilling inserts
